SD 4.0 Card Connector Push-Pull Bottom Mount Height 2.90mm
SD 4.0 Card Connector Push-Pull Bottom Mount Height 2.90mm
SD 4.0 Card Connector Push-Pull Bottom Mount Height 2.90mm
Model
SD 4.0 Card Connector(SD290-T1250-01)

Item specifics

Product Height
2.90mm
Usable Memory Card
SD 4.0/SD 3.0memory card
Base Material
LCP
Terminals Material
Phosphorous Bronze
Shell Material
Stainless Steel

Review

Description

Learn about Height 2.90mm SD 4.0 Card Connector

SD card socket connector

Secure Digital (SD) 4.0 Memory Card Connector

1.05mm Pitch SD 4.0 Memory Card Connector, Bottom Mount SMT Type, Push-Pull structure, 2.90mm Height

Advantage:
1. The product adopts a bottom mount type design, providing flexible adaptation to customers' internal device space layouts.

2.Backward compatible with SD 4.0/3.0 standards, supporting multiple memory card types.

3.Widely implemented in card reader products, enabling high-speed data transfer.

4.Complies with RoHS/REACH environmental certifications, meeting global market access standards.

Understand the Parameters of the Height 2.90mm SD 4.0 Card Connector

Technical Parameters
Rating Current:
0.5 A
Rating Voltage:
500 V
Contact Resistance:
100 mΩ
Insulation Resistance:
1000 MΩ
Useful Life:
5000 cycles
Additional Parameters
Transmission Rate:
300 Mb/s
Number of pins:
19
Number of interfaces:
1
Features:
High Transmission
Used for:
Computer/Card reader/Docking Station/Laptop/Digital Cameras
Download
2D Drawing PDF

Data Sheet

Detail Drawing of Height 2.90mm SD 4.0 Card Connector

SD 4.0 socket card connector
